Yamaha DXS12 Mk3 Active 12" Subwoofer

This is what Yamaha say about the DXS12:

The Yamaha DXS12mkIII is the most compact and portable model in Yamaha’s latest DXS Series powered subwoofer range, delivering impressive low-frequency performance in a space-saving design. Featuring a proprietary 12-inch high-durability woofer with a 3-inch voice coil, a newly developed 2500W Class-D amplifier, and an optimised bandpass cabinet, the DXS12mkIII produces deep, clear bass with exceptional power and clarity while minimising unwanted cabinet resonance.

Capable of delivering up to 132dB SPL, this professional active subwoofer is ideal for live sound, DJs, venues, and touring applications. Built-in D-XSUB processing extends low-frequency response down to 38Hz, while flexible DSP crossover settings and Cardioid Mode provide advanced bass control and improved on-stage sound management.

Designed to integrate seamlessly with Yamaha DXRmkIII loudspeakers, the DXS12mkIII creates a powerful, balanced PA system with outstanding impact and performance. Its rugged plywood enclosure is acoustically optimised for superior sound quality and long-term durability, while dual M20 and 35mm pole sockets ensure versatile installation options. Optional speaker wheels and a protective cover are available for enhanced portability and protection.

• System Type: Powered subwoofer, band-pass
• Frequency Range: 38 Hz – 140 Hz
• Maximum SPL: 132 dB
• LF Driver: 12" cone, 3" voice coil
• Amplifier Type: Class-D
• Power Output: 2500 W peak, 1250 W x2
• Cooling: Fan cooling, 5 speeds
• DSP: 32-bit / 96 kHz processing
• HPF: OFF, 50 Hz – 118 Hz, 12–48 dB/oct
• DSP Modes: NORMAL, XTENDED LF
• Inputs: Combo x2 (XLR/TRS)
• Input Impedance: 20 kΩ balanced, 10 kΩ unbalanced
• Maximum Input Level: +24 dBu
• Outputs: XLR THRU or DSP OUT x2
• Bluetooth: Version 5.0, A2DP (SBC, AAC), Class 1
• Remote Control: D-Remote (iOS/Android)
• Cabinet Material: Plywood
• Finish: Polyurea coating, black
• Handles: Side x2
• Pole Mount: 35 mm socket, M20 threaded
• Dimensions (W x H x D): 400 x 567 x 570 mm
• Weight: 33.0 kg
• Power Supply: 100–240 V, 50/60 Hz
• Power Consumption: 130 W (1/8 power), 40 W (idle)

• 12" Cone, 3" Voice coil proprietary high-durability speaker unit
• Newly developed 2500 W Class-D amplifier
• High-output woofer with an ideal bandpass cabinet design for superior bass response, delivering a maximum 132 dB SPL
• Built-in D-XSUB processing allows you to extend the frequency response even lower, up to 38 Hz
• Extremely flexible X-OVER settings with DSP
• Cardioid mode for bass management onstage
• Plywood cabinet is durable and acoustically optimised for maximum sound quality
• M20 and Ø35 mm dual pole sockets
• Optional Speaker Wheels (SPW-1) and Speaker Cover (SPCVR-DXS123)
